Uniview IPC2322EBR-P 2MP VF Network IR Bullet Camera

Uniview IPC2322EBR-P 2MP VF Network IR Bullet Camera   IPC2322EBR-P Camera Sensor 1/2.7″, 2 Megapixel, progressive scan CMOS Lens 2.8~12 [email protected] Angle of View(H) 90° ~ 28° Zoom/Focus Manual Shutter Auto/Manual, 1/6~1/8000s Min. Illumination Colour: 0.06 Lux (F1.4, 50IRE)Black & White: 0.03Lux (F1.4, 50IRE) Day/Night IR-cut filter with auto switch (ICR) S/N >52dB Video Max. Resolution 1920 × 1080 Video Compression H.264,MJPEG Frame Rate 1080P (1920×1080): Max. 30 fps; 720P (1280×720): Max. 30 fps; D1 (720×576): Max. 25 fps Video Streaming Triple 9:16 Corridor Mode Supported ROI Supported OSD Up to 8 OSDs Privacy Mask Up to 4 areas Audio Audio Compression G.711 Two-way audio Supported Storage Edge Storage Micro SD, up to 128 GB Network Protocols L2TP,IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP,PPPoE,RTP,RTSP, NTP,FTP,HTTP Compatible Integration ONVIF, API Interface Audio I/O Audio cable Input: impedance 35 kΩ; amplitude 2 V [p-p] Output: impedance 600 Ω; amplitude 2 V [p-p] Alarm I/O 1 / 1 Network 10M/100M Base-TX Ethernet General Power 12 V DC, or PoE (IEEE802.3 af) Power consumption: Max 8W Dimensions (L × W × H) 253.4 ×86 ×71.7 mm (9.98” × 3.4” × 2.8”) Material Cast aluminum Weight 0.58kg (1.28lb) Working Environment -35°C ~ 60°C (-31°F ~ 140°F), Humidity ≤ 95% RH(non-condensing) Ingress Protection IP66
